DZX Series Large Type Mining Linear Vibrating Screen

Ask Lasest Price
Brand Name :	CCRB
Model Number :	DZX3661
Certification :	ISO9001:2008, SGS
Price :	Negotiated
Payment Terms :	L/C, T/T
Supply Ability :	600 sets per year
Delivery Time :	Within 40 days

Add to Cart

Product Details
Company Profile

DZX Series Large Type Mining Linear Vibrating Screen

DZX Series Large Type Mining Linear Vibrating Screen

Introduction:

Large Type Mining Linear Vibrating Screen for process plant facilities are supplied in a diverse range of innovative modular designs suitable for coal, gold, metal applications.

Linear Vibrating Screen is used for medium, small size classification and material screening. It has varieties of application range:

Iron ore& gold powder
Coal powder
Aggregates
Sand &gravel
Hard rock, limestone and ore,etc

Mining Vibrating Screen Coal Vibrating Screen

Advantage:

Quick change of the drive unit
Replacement service for the CCRB double unbalance drive units
Constant infinitely variable stroke
Low overall height owing to the horizontal arrangement of assemblies
ISO9001:2008 and SGS Audited

**Linear Vibrating Screen Technical Parameters:**
Model	Screen Surface			Feeding Size(mm)	Capacity(m³/h)	Motor
Model	Deck	Area(m²)	Mesh Size(mm)	Feeding Size(mm)	Capacity(m³/h)	Power(kw)	Qty
DZX3045	1	13.5	0.25-13	<100	6.2-305	30	1
DZX3052	1	15.6	0.25-13	<100	6.2-305	30	1
2DZX3052	2	2*15.6	Upper3-50 Lower0.25-13	<100	47-680	45	1
DZX3061	1	18.3	0.25-13	<100	6.2-305	37	1
2DZX3061	2	2*18.3	Upper3-50 Lower0.25-13	<100	55-680	45	1
DZX3645	1	16.2	0.25-13	<100	7.4-366	37	1
DZX3652	1	18.72	0.25-13	<100	7.4-366	37	1
2DZX3652	2	2*18.72	Upper3-50 Lower0.25-13	<100	56-830	55	1
DZX3661	1	21.96	0.25-13	<100	7.4-366	45	1
2DZX3661	2	2*21.96	Upper3-50 Lower0.25-13	<100	65-830	75	1
DZX3673	1	26.28	0.25-13	<100	8.5-366	45	1
2DZX3673	2	2*26.28	Upper3-50 Lower0.25-13	<100	78-830	75	1

Linear Vibrating Sieve Stone Vibrating Screen

Related Products:

Circular Vibrating Screen&Coal Sizer

Coal Crushing Plant&Banana Screen

Apron Feeder Breaker&Scraper Feeder Breaker

Crawler Type Mobile Crushing Plant&Trailer Type Mobile Crushing Plant

Vibrating Feeder&Belt Feeder

Portable Jaw Crusher&Impact Crusher

Cone Crusher&Sand Making Machine

Impeller Sand Washer&Spiral Sand Washer

After-sales Service:

Provide professional staff training for customers

1. Service engineer offers spot training and equipment operation manual.

2. After-sales personnel visit customers on a regular basis.

3. Design engineer provides professional service for customers for free.
